Verfügbare Größen
M, L, XL

Federweg (V/H)
160 mm / 150 mm

RAHMEN

Foxy 29 6061 Aluminium Stealth Evo, hydrogeformter Rohrsatz, Zero Suspension System, 150mm Federweg, Forward Geometry, einteilige Monoblock Wippe, Boost 12x148mm Hinterachse, 73mm BSA Innenlager, spezifisches Design für 1-fach Antriebe, interne Leitungsverlegung für versenkbare Sattelstütze, gedichtete „MAX Capacity“ Lager, ISCG 05

VORBAU

Onoff Sulfur FG 30mm 0º, geschmiedetes 6061 Aluminium, 31,8mm Lenkerdurchmesser

STEUERSATZ

Onoff Saturn konifiziert für 1-1/8″ bis 1-1/2” Steuerrohr, gedichtete ACB Lager, oben 41×30,2x7x45°x45°, unten 51,9x40x8x45°x45°

SPEICHEN

DT Champion, gerader Speichenkopf

SCHALTWERK

Sram SX Eagle, Roller Bearing Clutch Typ 3, Cage Lock, langer Käfig, 1×12-Gang, X-Actuation 1:1

SCHALTHEBEL

Sram Trigger SX Eagle, 12-Gang, X-Actuation 1:1

SCHALTAUGE

Mondraker M068

SATTELSTÜTZE

Onoff Pija versenkbar, interne Leitungsverlegung, Durchmesser 31,6mm, Größe S: 337x100mm, Größe M 387x125mm, Größe L: 425x150mm, Größe XL: 465x170mm

SATTEL

SDG BEL-AIR 3.0, LPU Schaum, Stahl Streben

REIFEN VORN

Maxxis Minion DHF 29×2.5 WT, Tubeless Ready, 3C MAXX TERRA Compound, EXO+ Protection, 120TPI, faltbar

REIFEN HINTEN

Maxxis Aggressor 29×2.3, Tubeless Ready, Dual Compound, Exo Protection, 60TPI, faltbar

NABE VORN

DT 370, Boost 15x110mm, IS 6-Loch

NABE HINTEN

DT 370, Boost 12x148mm, 18Z Ratchet LN System, IS 6-Loch

LENKER

Onoff Sulfur 1.0, doppelt konifiziertes 6061 Aluminium, Erhöhung: 20mm, Breite: 800mm, 9º horizontale Kröpfung/Backsweep, 5º vertikale Kröpfung/Upsweep, 31,8mm Lenkerdurchmesser

KURBELN

Sram SX Eagle, Boost, DUB Achse, Direct Mount Kettenblatt, Größe S/M: 170mm, Größe L/XL: 175mm

KETTENBLÄTTER

32Z, Stahl, X-Sync 2

KETTE

Sram SX Eagle, 12-Gang, Powerlock

KASETTE

Sram PG-1210, 11-50Z, 12-Gang

INNENLAGER

Sram DUB BSA, gedichtete Lager, 73mm

GRIFFE

Onoff Diamond, lock-on einfach, 135mm

GEWICHT

15,5 kg

GABEL

Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, konifiziertes Steuerrohr, 15x110mm Achse, Offset 44mm. Einstellungen: Sweep Adjust Druckstufe, Low-Speed Zugstufe, Luftdruck

FELGEN

DT Swiss E1900 Spline 29, 30mm Innenbreite, beschichtetes Aluminium, Tubeless Ready, 28 Speichen

DÄMPFER

Fox Float DPS LV EVOL Performance, 205×62,5mm. Einstellungen: Zugstufe, 3-stufige Druckstufe (Open/Mid/Lock), Luftdruck. Obere Befestigung: Trunnion, untere Lager: 22,2x10mm

BREMSHEBEL

Sram G2 R, Griffweite werkzeuglos einstellbar

BREMSE VORNE

Sram G2 R, 4-Kolben Bremssattel, einteilige 6-Loch Centerline 200mm Bremsscheibe, organische Bremsbeläge mit Rückplatte aus Stahl

BREMSE HINTEN

Sram G2 R, 4-Kolben Bremssattel, einteilige 6-Loch Centerline 180mm Bremsscheibe, organische Bremsbeläge mit Rückplatte aus Stahl
